Security Research

Nevada Ransomware: Yet Another Nokoyawa Variant


Key Takeaways

  • Nevada ransomware was advertised in criminal forums in December 2022 as part of a new ransomware-as-a-service affiliate program
  • Nevada is written in the Rust programming language with support for Linux and 64-bit versions of Windows
  • Zscaler ThreatLabz has identified significant code similarities between Nevada and Nokoyawa ransomware including debug strings, command-line arguments and encryption algorithms
  • The Nokoyawa ransomware codebase has been continuously modified with at least four distinct variants (including Nevada) that have emerged since February 2022
  • The Nokoyawa threat group appears to operate two parallel code branches written in different programming languages designed to confuse researchers and evade detection

Zscaler ThreatLabz has been tracking the Nokoyawa ransomware family and its predecessors including Karma and Nemty ransomware. The original version of Nokoyawa ransomware was introduced in February 2022 and written in the C programming language. File encryption utilized asymmetric Elliptic Curve Cryptography (ECC) with Curve SECT233R1 (a.k.a. NIST B-233) using the Tiny-ECDH open source library combined with a per file Salsa20 symmetric key. In September 2022, a Rust-based version of Nokoyawa ransomware was released. This new version used Salsa20 for symmetric encryption, but the ECC algorithm was replaced with Curve25519. In December 2022, Nevada ransomware was advertised in criminal forums. ThreatLabz has determined that Nevada shares significant code with the Rust-based variant of Nokoyawa. In January 2023, ThreatLabz also identified another version of Nokoyawa written in C that is similar to the original version, but uses the same configuration options (passed via the command-line) as the Rust-based Nokoyawa 2.0.

In this blog, we analyze Nevada ransomware and how it compares to the other versions of Nokoyawa ransomware. Based on the numerous similarities, the Nokoyawa threat group appears to utilize two separate branches for ransomware attacks.

Technical Analysis

ThreatLabz has identified at least four distinct versions of Nokoyawa ransomware. For clarity, we will use the version numbers 1.0, 1.1, 2.0 and 2.1 (Nevada) based on code similarities. Table 1 illustrates the similarities and differences between all four versions of Nokoyawa ransomware including Nevada.



Attribute

Nokoyawa 1.0

Nokoyawa 1.1

Nokoyawa 2.0

Nokoyawa 2.1

(Nevada)

Encryption algorithms

SECT233R1 + Salsa20

SECT233R1 + Salsa20

X25519 + Salsa20

X25519 + Salsa20

Encryption library

Tiny-ECDH

Tiny-ECDH

x25519_dalek

x25519_dalek

Programming language

C/C++

C/C++

Rust

Rust

Encryption Parameters

Hardcoded

Passed via command-line

Passed via command-line

Hardcoded

Import Hashing

No

Yes

No

No

CIS Exclusion

No

No

Yes

Yes

Architecture

x64

x64

x64

x64

Earliest known compilation date

February 2022

January 2023

September 2022

January 2023



Table 1. Comparison between different versions of Nokoyawa ransomware

There are a few commonalities between all Nokoyawa variants such as being compiled only for 64-bit versions of Windows and using a relatively obscure method to delete Windows Shadow Copies. The latter entails calling the function DeviceIoControl (shown in Figure 1) with the undocumented control code parameter IOCTL_VOLSNAP_SET_MAX_DIFF_AREA_SIZE (0x53C028) with a maximum size of 1, which causes Windows to delete all shadow copies as a result.

Figure 1. Nokoyawa/Nevada code to delete Windows Shadow Copies

Figure 1. Nokoyawa/Nevada code to delete Windows Shadow Copies

All versions of Nokoyawa support the command-line parameters --file (to encrypt a single file) and --dir (to encrypt a directory). However, Nokoyawa 1.1 and 2.0 require a configuration to execute the ransomware via the --config command-line parameter. The configuration parameter is a Base64 encoded JSON object that has the following keys and values shown in Table 2.




Key

Description

NOTE_NAME

Ransom note filename

NOTE_CONTENT

Ransom note content

EXTENSION

Encrypted file extension (also used as the Salsa20 nonce)

ECC_PUBLIC

Curve25519 public key

SKIP_EXTS

File extensions that will not be encrypted

SKIP_DIRS

Directories that will not be encrypted

ENCRYPT_NETWORK

Encrypt network shares

DELETE_SHADOW

Delete Windows shadow copies

LOAD_HIDDEN_DRIVES

Unhide hidden drives and encrypt files



Table 2. Nokoyawa 1.1 and Nokoyawa 2.0 ransomware configuration parameters

Nokoyawa 1.1 also has a --safe-mode command-line option to reboot the system into Windows safe mode prior to file encryption to maximize the number of files that can be encrypted by loading the minimal set of applications, and therefore, minimize the number of open file handles that may interfere with encryption. In addition, Nokoyawa 1.1 is the only variant that obfuscates the Windows API functions that are called during runtime by resolving each name via CRC32 hash.

In Nevada ransomware, the encryption parameters are hardcoded in the binary, but the other command-line options are virtually identical to Nokoyawa 1.1 and 2.0 (with the exception of a new feature to self-delete the ransomware binary after file encryption is complete). Nevada also supports a -help command-line argument, which prints the usage shown below in Figure 2.

Figure 2. Nevada ransomware command-line help

Figure 2. Nevada ransomware command-line help

In order to reduce the risk of law enforcement actions, Both Nokoyawa 2.0 and Nevada check whether the infected system is located in a former Commonwealth of Independent States (CIS) country. The former calls the Windows API GetSystemDefaultLCID for language IDs (between 1049-1092 or 2073) and the latter calls GetUserDefaultUILanguage (between 1049-1090) to determine the system's locale and language, respectively. Some of these language IDs include countries outside of the CIS countries, which may be to simplify the code by adding a range of values rather than individually checking each value.

Nokoyawa 1.0 and Nokoyawa 1.1 share about 39% of the same code, while Nokoyawa 2.0 and Nevada share more than 87% of the same code according to BinDiff.



Debug Print Statements

Another similarity between Nokoyawa 2.0 and Nevada are debug print statements, which are very similar or identical. Figure 3 shows an example for a function that creates a thread and prints a debug statement to the console.

Figure 3. Comparison of CreateThread function and debug print statements in Nokoyawa 2.0 (left) and Nevada (right)



Figure 3. Comparison of CreateThread function and debug print statements in Nokoyawa 2.0 (left) and Nevada (right)

Many strings have also been slightly altered between Nokoyawa 2.0 and Nevada as shown in Table 3.



Nokoyawa 2.0

Nokoyawa 2.1

(Nevada)

CIS lang detected! Stop working...

CIS. STOP!

Successfully deleted shadow copies fromShadow copies deleted from

Couldn't create ransom note

Failed to create ransom note

Couldn't seek file:

Failed to seek file:

Couldn't read file:

Failed to read file:

Couldn't write to file:

Failed to write file:

Couldn't rename file

Failed to rename file



Table 3. Comparison between debug print strings in Nokoyawa 2.0 (left) and Nevada (right)



Encryption Algorithms

Nokoyawa 1.0 and 1.1 use the elliptic curve SECT233R1 (NIST B-233) via the Tiny-ECDH library to generate a per file Salsa20 key. Nokoyawa 2.0 and Nevada use Curve25519 via the open source x25519_dalek Rust library to derive a Salsa20 encryption key per file. In Nokoyawa 1.1 and 2.0, the file extension (as described in Table 2) is used as the nonce. The original version of Nokoyawa and Nevada ransomware use the hardcoded nonce values lvcelvce and pmarpmar, respectively.

Conclusion

Zscaler ThreatLabz has identified two parallel versions of Nokoyawa ransomware with implementations in C and Rust. These two branches may be indicative of a source code leak, or designed to evade host-based security software and divert attention. In conclusion, Nevada ransomware appears to be the latest variant of the Rust-based version of Nokoyawa rather than an entirely new ransomware family.

Cloud Sandbox Detection

Zscaler sandbox coverage



In addition to sandbox detections, Zscaler’s multilayered cloud security platform detects indicators related to Nokoyawa at various levels with the following threat names:

Indicators Of Compromise (IOCs)

SHA256

Description

a32b7e40fc353fd2f13307d8bfe1c7c634c8c897b80e72a9872baa9a1da08c46

Nokoyawa ransomware 1.0

3339ba53e1f05f91dbe907d187489dbaba6c801f7af6fd06521f3ba8c484ec6c

Nokoyawa ransomware 1.1

7095beafff5837070a89407c1bf3c6acf8221ed786e0697f6c578d4c3de0efd6

Nokoyawa ransomware 2.0

855f411bd0667b650c4f2fd3c9fbb4fa9209cf40b0d655fa9304dcdd956e0808

Nokoyawa ransomware 2.1

(Nevada)
