Security Research

WarHawk: the New Backdoor in the Arsenal of the SideWinder APT Group

NIRAJ SHIVTARKAR, AVINASH KUMAR
October 21, 2022 - 18 min read

Recently, Zscaler ThreatLabz discovered a new malware being used by the SideWinder APT threat group in campaigns targeting Pakistan: a backdoor we’ve called “WarHawk.” SideWinder APT, aka Rattlesnake or T-APT4, is a suspected Indian Threat Actor Group active since at least 2012, with a history of targeting government, military, and businesses throughout Asia, particularly Pakistan. The newly discovered WarHawk backdoor contains various malicious modules that deliver Cobalt Strike, incorporating new TTPs such as KernelCallBackTable Injection and Pakistan Standard Time zone check in order to ensure a victorious campaign.

Zscaler’s ThreatLabz research team has performed an in-depth analysis of the WarHawk backdoor and its use in threat campaigns below.



Key Features of this Attack

  • SideWinder APT campaign targets Pakistan with a new backdoor named “WarHawk”
  • The WarHawk Backdoor consists of four modules:
    • Download & Execute Module
    • Command Execution Module
    • File Manager InfoExfil Module
    • UploadFromC2 Module
  • WarHawk is commissioned to deliver Cobalt Strike as the final payload which has been downloaded and executed using the Download & Execute Module.
  • The custom Cobalt Strike loader used by the SideWinder APT leverages the KernelCallBackTable Process injection (a technique previously used by FinFisher and Lazarus APT) to load the Cobalt Strike beacon, along with a Time Zone check that makes sure that the loader is executed only when under Pakistan Standard Time.
  • The SideWinder APT makes use of ISO Files bundled with a LNK file, a decoy PDF displaying copies of cybersecurity advisories released by the Pakistan Cabinet Division (used as a lure), and the WarHawk backdoor which is executed by the LNK File.
  • We discovered the ISO file hosted on the legitimate website of Pakistan's National Electric Power Regulatory Authority “nepra[.]org[.]pk” which may indicate a compromise of their web server.
  • We were able to attribute this campaign to the SideWinder APT based on the reuse of network infrastructure that has previously been used by SideWinder for various espionage activities against Pakistan.



Campaign Analysis

In the month of September 2022, we came across an ISO File “32-Advisory-No-32.iso” hosted on the official website of the Pakistan’s National Electric Power Regulatory Authority “nepra[.]org[.]pk.” NEPRA is commissioned to provide safe, reliable, efficient and affordable electric power to the electricity consumers of Pakistan. It is possible that this ISO file was uploaded to the server due to web server compromise.

ISO URL: https[:]//nepra[.]org[.]pk/css/32-Advisory-No-32[.]iso


Fig 1. National Electric Power Regulatory Authority Website



We then downloaded the ISO File from the above mentioned URL which consisted of the following bundled files.

  • 32-Advisory-No-32-2022.lnk - Malicious LNK File
  • 32-Advisory-No-32-2022.pdf - Decoy PDF
  • RtlAudioDriver.exe - Malicious Binary


  Fig 2. Contents of the Malicious ISO File



The .LNK File had a PDF icon to lure the victim into execution. Once the .LNK File is executed, it runs the malicious binary “RtlAudioDriver.exe” along with the decoy PDF “32-Advisory-No-32-2022.pdf” to distract the victims. It does so with the help of the command  shown in the following screenshot.


Fig 3. Execution of Malicious Binary & Decoy PDF via the LNK File



Following is the Decoy PDF executed by the LNK File with the Subject: Phishing Site - Masqueraded Links (Advisory No. 32) in the screenshot below


                                           Fig 4. Decoy PDF



The content for the PDF was copied from an actual advisory  previously released by the Cabinet Division of Pakistan Government regarding the “Masqueraded Links used by the Malicious Actors in Phishing Campaigns” on their official website cabinet[.]gov[.]pk

Link:
https[:]//cabinet[.]gov[.]pk/SiteImage/Misc/files/NTISB%20Advisories/2022/32-Advisory-No-32-2022[.]pdf




        Fig 5. Original Advisory on Pakistan Government Cabinet Division Website



Alongside the Decoy PDF, the Malicious binary “RtlAudioDriver.exe'' is also executed by the LNK File.

A few days after this initial discovery, ThreatLabz came across another related ISO File named “33-Advisory-No-33-2022.pdf.iso” which similarly copied a real “Advisory No. 33” from the Pakistan Cabinet Website as a lure. This ISO similarly consisted of three files, including aWindows Shortcut file commissioned to execute the binary “MSbuild.exe” and a decoy PDF “33-Advisory-No-33-2022.pdf” to fool the victims as shown in the screenshot below.



Fig 6. 33-Advisory-No-33-2022 Campaign



Upon analyzing both the binaries “RtlAudioDriver.exe” and “MsBuild.exe,” we discovered that this was a new backdoor added to the arsenal of the SideWinder APT Group. We termed it “WarHawk” Backdoor based on the CnC panel title, as shown in the below screenshot. In this case, the “MsBuild” binary is the newer version of the backdoor, with a few additional features compared to “RtlAudioDriver” (the older one). Below, we will share our in-depth analysis to understand the inner workings of the WarHawk Backdoor.


 Fig 7. WarHawk CnC Panel





Analysis - WarHawk Backdoor



The “WarHawk Backdoor” disguises itself as legit applications to lure unsuspecting victims into execution, as shown in the screenshot below.


Fig 8. WarHawk Backdoor disguises as legit applications



Once executed, the WarHawk first enumerates the base address of the Kernel32.dll by iterating the InMemoryOrderModuleList linked list present in the Process Environment Block (PEB). The instructions it uses are shown in the screenshot below.


Fig 9. Enumerate Base Address of Kernel32.dll via PEB



Once the base address of Kernel32.dll is enumerated, WarHawk then decrypts a set of API & DLL names using a String Decryption Routine which takes the Encrypted Hex Bytes as an input and then subtracts each byte with the Key: "0x42" in order to decrypt the string.


Fig 10. String Decryption Routine - WarHawk



Leveraging the decryption logic, we wrote a string decryptor for the WarHawk backdoor through which we were able to decrypt the following Strings from the Encrypted Hex Blobs:



LoadLibraryA

GetUserNameA

GetCurrentHwProfileA

Advapi32

GetProcAddress

GetComputerNameA




 Fig 11. Decrypted Strings from the WarHawk String Decryptor



Initially the WarHawk decrypts the LoadLibraryA and GetProcAddress API Names, then loops through all the exported functions from the Export Table and compares them with the decrypted function names. If the comparison matches, it fetches the address of the corresponding function name—in this case, LoadLibraryA() and GetProcAddress().




Fig 12. Fetches the Address of the Decrypted Function Names



Next, it decrypts the string “Advapi32'' and loads the Advapi32.dll into the virtual memory with the help of LoadLibraryA(). It then retrieves the address of the GetCurrentHWProfileA() function via the GetProcAddress() from the Advapi32.dll. Here, the GetCurrentHWProfileA string is decrypted via a similar string decryption routine. After decryption, it executes the GetCurrentHWProfileA() to retrieve the GUID (Globally Unique Identifier) for the hardware profile.




Fig 13. Retrieves the GUID for the hardware profile using GetCurrentHWProfileA



The retrieved GUID is then concatenated with the _hwid parameter in the following JSON format:

{ "_hwid": "{GUID}" }

As shown in the screenshot below:




 Fig 14. GUID concatenated with the _hwid parameter



Further, the WarHawk Backdoor sends across an initial beacon POST request to the hardcoded Command & Control Server “146[.]190[.]235[.]137” using the HTTPSendRequestW() with the GUID in the JSON format as its parameters and the request URL “/wh/glass.php,” as shown and explained in the screenshot below:




Fig 15. Initial Beacon Request to the CnC Server with the GUID



Now it reads the response via InternetReadFile(). If the response is “0” in the newer sample and “1” in the older sample, it gathers the following System Information as mentioned below and then sleeps for 2 seconds:


  • Retrieves the Computer/NetBios Name via GetComputerNameA()
  • Retrieves the UserName via GetUserNameA()
  • Retrieves the Windows Product Name from the “SOFTWARE\Microsoft\Windows NT\CurrentVersion\ProductName” Registry Key via the RegQueryValueExA()

Once all of the above mentioned system information has been gathered it is arranged in the following JSON format using the similar wsprintf() method explained previously:

{ "_hwid": "{GUID}", "_computer": "Computer_Name", "_username": "User_Name", "_os": "Windows_Product_Name" }



It then sends across the System information in the JSON format to the Command & Control server using the HTTPSendRequestW(), as shown and explained in the screenshot below:


Fig 16. Gathered System Information sent across to the CnC server



After sending the System Information, it sends a JSON ping request to the Command and Control server as shown in the screenshot below, using the similar WinINet functions:


Fig 17. JSON Ping Request to the CnC Server



If the response to the JSON ping request is “del” as shown in the screenshot below, WarHawk skips the main malicious functions and sends across a “_del”: “true” request to the Command and Control and then exits the process as shown in Fig 19.




Fig 18. JSON Ping Request to the CnC Server





Fig 19. Sends DEL Request and Exits the Process



If the response to the JSON ping request is not “del”, the WarHawk Backdoor executes the backdoor modules integrated in WarHawk:



Download & Execute Module

This module is responsible for downloading and executing additional payloads from the remote URL provided by the CnC server. At first, the WarHawk sends across a task initiation request to the Command and Control as shown in the screenshot below. This request is in the JSON format using a similar Send_Req function incorporating the WinINet functions.


Fig 20. WarHawk Task Initiation Request



The CnC responds to this request in the following JSON format with the id, type, and remote URL:

{ "_task": "true", "_id": "id_no", "_type": "type_no", "_url": "Remote_URL" }

In the below screenshot, we can see the response from the CnC. It contains a remote URL that leads to the Stage-2 payload, which would be downloaded and executed further by the backdoor.


Fig 21. Response to Task Initiation Request consisting of the Remote URL



Once the JSON response is received, the WarHawk then parses the parameters _id, _type and _url using an ultralight weight JSON parser library “cJSON,” as shown below.


Fig 22. Parse JSON Response parameters using cJSON


Further it checks the parsed _type parameter. If _type  value is “1” the backdoor downloads the additional payload from the parsed _url parameter containing the Remote URL, with the help of the URLDownloadToFileA function, into the Temp directory where the filename is randomly generated and concatenated with the extension provided in the remote URL. Once the payload is downloaded the backdoor executes the downloaded payload with the help of the ShellExecuteA() function.

If the _type is “2” then the payload must be a “Dynamic Link Library,” as in this case the payload is downloaded via URLDownloadToFileA and then loaded into the virtual memory using LoadLibrary().



Finally, if the _type is “3,” then the process is similar to the _type value “1”. The only difference is that the process exits at the end through the ExitProcess() function.


Fig 23. Download and Execute Additional Payloads from the Remote URL



Once the Stage-2 payload is downloaded and executed on the infected machine and the task is completed, the WarHawk sends across a Task Completion request to the Command and Control server in the following manner:


Fig 24. WarHawk Task Completion Request


Thus, in the following manner the additional payloads are downloaded and executed  from the Remote URL served from the CnC server. In this case there are multiple payloads which are downloaded and executed by the WarHawk backdoor which are analyzed later in the blog.




Command Execution Module

The command execution module is responsible for execution of system commands on the infected machine received from the Command & Control.  WarHawk starts by sending across the Command Execution Initiation request with the GUID of the system as shown in the screenshot below.


Fig 25. WarHawk Command Execution Initiation Request



The response to this Initiation request consists of the command to be executed. Let’s analyze the routine assuming that the received command is “whoami”. The received command is passed as an argument to the CMD.exe process which has been spawned using ShellExecuteA. The command arguments passed to the CMD.exe process can be seen in the screenshot below.


Fig 26. WarHawk Command Execution



In this case, the output of the command received from the CnC “whoami” is stored in a “.bin” file in the Temp directory where the file name is generated using a random name generator function, as shown above.


Further, this “.bin” file in the Temp Directory is read using ReadFile() and then deleted to clear its tracks. The command output content is then base64 encoded, arranged in the following JSON format, and then sent across to the Control Control server 146[.]190[.]235[.]137 using HttpSendRequestW():

{ "_hwid": "GUID", "_cmd_done": "true", “_response”:”base64enc_cmd_output”}


Fig 27. Sending Command Output response to CnC Server


If there is no output of the command executed on the machine, it sets the _response parameter as “0” in the JSON response.

Thus, in the following manner the WarHawk performs the command execution routine where it receives the commands from the Command and Control and the backdoor executes them and sends the output to the CnC in an base64 encoded platform. Here the routine executes in a loop until the response to the JSON Ping request is not “del,” allowing the Threat actors to execute multiple commands on the infected machine.




File Manager InfoExfil Module

The following module is responsible for gathering and sending across the File Manager information by initially sending across an Module initiation request to the CnC server as shown below:


Fig 28. File Manager Initiation Request



Now if the response to the initiation request is “drive” the WarHawk determines the drive type by looping through the drive letters from A-Z. Itfirst checks whether the drive exists with the help of PathFileExistsA(); if it exists, it then fetches the drive type using GetDriveTypeA() such as DRIVE_FIXED or DRIVE_REMOVABLE as shown and explained in the below screenshot:


Fig 29. Determine Drive Type



After this, the gathered information consisting of the existing drives and their types is sent across to the CnC in the following JSON format:




Fig 30. Drive Information sent across to CnC in JSON Format



Further if the response to the initiation request is a Directory Path such as “C:\Dump\,” then the backdoor searches in the following directory for files and folders recursively using FindFirstFileA() and FindNextFileA(). Whilst performing the recursion it fetches the File Name, File size, Modification date, File Type, and then towards the end sends across all the information to the CnC Server in the JSON format:


Fig 31. WarHawk sends across File/Folder information to CnC in JSON Format



UploadFromC2 Module

The following module is a new feature added in the latest WarHawk Backdoor (MsBuild.exe),  allowing the threat actor to upload files on the infected machine from the Command and Control Server. Initially the UploadFromC2 Module sends across a routine initiation request to the CnC server in the following JSON format:


Fig 32. UploadFromC2 Module initiation request



The response to this request should be a JSON response received  from the CnC server consisting of following two parameters:


  1. _upload - File name of the target file to be uploaded on the infected machine from the CnC server
  2. _path - Path where the target uploaded file is to be saved on the infected machine

Further the JSON response is parsed using the previously used cJSON Library, and then the _upload value is concatenated with the hardcoded CnC URL: http[:]\\146[.]190[.]235[.]137\wh. For example, if _upload = “stage2.exe,” the final URL becomes http[:]\\146[.]190[.]235[.]137\wh\stage2.exe. The WarHawk then downloads the file from the final CnC URL: http[:]\\146[.]190[.]235[.]137\wh\stage2.exe using URLDownloadToFileA() and writes it to the current directory using the same file name “stage2.exe” (or, if the  _path value exists, it writes the downloaded file to that path as shown in the routine below):


Fig 33. UploadFromC2 Module Routine



As can be seen from the screenshot, if the file has been downloaded successfully the WarHawk backdoor then sends a JSON request to the CnC Server with “_uploadstatus”:“true” and if not sends across “_uploadstatus”:”false”.

In the following way the WarHawk Backdoor performs its espionage activities by incorporating various modules.



Stage 2 Analysis

Based on the analysis of the WarHawk backdoor, we are aware that the backdoor has the capability to download and execute additional payloads. While tracking the SideWinder’s espionage campaign we came across WarHawk downloading three additional Stage-2 Payloads from the Command and Control at the time of writing this blog. Below, we analyze the Stage-2 Payloads downloaded by WarHawk.

  • Snitch.exe - Cobalt Strike Loader using KernelCallbackTable Process Injection

The WarHawk downloads and executes the Cobalt Strike Loader using the Download & Execution Module from CnC URL: http[:]//146[.]190[.]235[.]137/Snitch.exe. Once executed the Loader performs the following Anti-Analysis checks:

  • Anti-Sandbox:

-  Checks whether the Numbers of Processors are at least two using GetSystemInfo()

-  Checks Minimum RAM using GlobalMemoryStatusEx()

-  Checks whether the Hard Disk drive size is greater than 40GB via sending a IOCTL_DISK_GET_DRIVE_GEOMETRY control code to the PhysicalDrive0 via DeviceIoControl

  • Time-Zone Check: The Loader performs the Time Zone Check using GetDynamicTimeZoneInformation(), It inspects whether the time zone under which the code executed is “Pakistan Standard Time;” if not, the loader does not perform any malicious actions and exits the process. From this check we can deduce that the malware is specifically targeted towards Pakistan by the SideWinder APT Group:


Fig 34. Anti-Analysis Checks



Once all the Anti-Analysis Checks are satisfied, the loader then unhooks the NTDLL.dll (hooked) by mapping another fresh copy of NTDLL using MapViewOfFile() in memory and then replaces the .text section of the hooked NTDLL with the .text section of the fresh NTDLL. This technique allows the Loader to evade Userland API hooks placed on the Native API’s by EDRs.




Fig 35. NTDLL UnHooking



Further the loader performs the KernelCallbackTable Process Injection in order to inject shellcode into a remote process. This technique was previously used by FinFisher and Lazarus APT Group, but now is also used by SideWinder APT. The process injection code in this case has been reused from the following blog as can be seen in the screenshot below:


Fig 36.  Reused KernelCallbackTable Process Injection Routine



Now once initiated the Loader injects the shellcode in the remote process “notepad.exe” and then executes the payload when the SendMessageW function is called with WM_COPYDATA, which in turn invokes fnCOPYDATA which points to the address of the payload. The following sample was crashing once executed but upon patching a few instructions related to WaitForInputIdle() function we were able to execute it seamlessly and then debug the shellcode which then decrypted and loaded the embedded binary in the virtual memory. We further dumped the loaded binary which was a Cobalt Strike Beacon as seen in the screenshot below:


Fig 37.  Cobalt Strike Beacon Injected into the Remote Process via KernelCallbackTable Process Injection



Further we found multiple similar CS Loaders and extracted the configuration for the Cobalt Strike Beacons:


Beacon Type: Hybrid HTTP DNS

Cobalt Strike C2: fia-gov[.]org



Fig 38.  Cobalt Strike Configuration - 1



  • OneDrive.exe and DDRA.exe - Cobalt Strike Beacons



Along with the CS Loader, both of these payloads were also downloaded and executed from the CnC Server URL: http[:]//146[.]190[.]235[.]137/OneDrive.exe and http[:]//146[.]190[.]235[.]137/DDRA.exe. We extracted the configuration for both the Cobalt Strike beacons with similar CnC servers as seen in the screenshot below:

DDRA.exe -

Beacon Type: Hybrid HTTP DNS

Cobalt Strike C2: fia-gov[.]org


Fig 39.  Cobalt Strike Configuration - 2

OneDrive.exe
Beacon Type: Hybrid HTTP DNS

Cobalt Strike C2: fia-gov[.]org


Fig 40.  Cobalt Strike Configuration - 3



The CnC server domain: fia-gov[.]org used by the SideWinder APT mimics the domain name of Pakistan’s Federal Investigation Agency fia[.]gov[.]pk which is the premier agency of Pakistan at national level to investigate federal crimes.
Also we found another similar CS Loader sample with the CnC server as: customs-lk[.]org, in this case it mimics the domain name of Sri Lanka Customs customs[.]gov[.]lk, possibly a SideWinder campaign targeting Sri Lanka. The “campaign_id” in this case is similar to the CS Loader analyzed previously as can be seen in the screenshot below.


Fig 41.  Cobalt Strike Configuration - 4





Attribution to SideWinder APT

SideWinder APT is reckoned as a Indian Threat Actor Group predominantly targeting Pakistan. We were able to attribute the following campaign to the SideWinder APT based on the network infrastructure as shown below in the graph.


Fig 42.  SideWinder Network Infrastructure



As can be seen in the above screenshot, the IP: 3[.]239[.]29[.]103 hosts the domains “fia-gov[.]org” and “customs-lk[.]org” which were the CnC servers for the Cobalt Strike beacons in the following campaign as shown earlier. Now if we take a look at the following other domains hosted on the same IP:

  • nationalhelpdesk[.]pk
  • mofa-pk[.]org
  • sngpl[.]org[.]pk


These domains were previously reported and were actively used by the SideWinder APT Group for espionage campaigns. Based on the reuse of the network infrastructure we can deduce that this WarHawk campaign is also performed by the SideWinder APT Group targeting Pakistan.

The indicators listed below also assist us in determining that the campaign is targeted at Pakistan:


  •  ISO files hosted on the Pakistan’s National Electric Power Regulatory Authority website
  • Advisories released by the Pakistan’s Cabinet Division used as a lure
  • Time Zone check for “Pakistan Standard Time” which makes sure that the malware is only executed under Pakistan Standard Time.



Zscaler Sandbox Coverage:




Fig. 43 The Zscaler Cloud Sandbox successfully detected the WarHawk backdoor



Win32.Backdoor.WarHawk



Conclusion



The SideWinder APT Group is continuously evolving their tactics and adding new malware to their arsenal in order to carry out successful espionage attack campaigns against their targets. The Zscaler ThreatLabz team will continue to monitor these attacks to help keep our customers safe



MITRE ATT&CK TTP MAPPING


ID

TACTIC

TECHNIQUE

T1566

Initial Access

Phishing

T1190

Initial Access

Exploit Public Facing Application

T1204

Execution

User Execution

T1059

Execution

Command and Scripting Interpreter

T1140

Defense Evasion

Deobfuscate/Decode Files or Information

T1564

Defense Evasion

Hide Artifacts

T1055

Defense Evasion

Process Injection

T1071.001

Command and Control

Application Layer Protocols - Web Protocols

T1041

Exfiltration

Exfiltration over C2 Channel




IoCs:



ISO:



32-Advisory-No-32.iso: d510808a743e6afc705fc648ca7f896a

URL: nepra[.]org[.]pk/css/32-Advisory-No-32[.]iso



33-Advisory-No-33-2022.pdf.iso: 63d6d8213d9cc070b2a3dfd3c5866564



WarHawk Backdoor:



WarHawk_v1: 8f9cf5c828cb02c83f8df52ccae03e2a
WarHawk_v1.1: 5cff6896e0505e8d6d98bff35d10c43a

CnC: 146[.]190[.]235[.]137/wh/glass[.]php



Cobalt Strike:



Snitch.exe CS Loader: ec33c5e1773b510e323bea8f70dcddb0

URL: 146[.]190[.]235[.]137/Snitch[.]exe



OneDrive.exe CS Beacon: d0acccab52778b77c96346194e38b244
URL: 146[.]190[.]235[.]137/OneDrive[.]exe



DDRA.exe CS Beacon: 40f86b56ab79e94893e4c6f1a0a099a1

URL: 146[.]190[.]235[.]137/DDRA[.]exe



Cobalt Strike CnC: fia-gov[.]org & customs-lk[.]org
